HT MC30 - Basic Temperature Regulator for Mounting Rails
HT MC 30 is a compact, basic regulating device with adjustable switching hysteresis, designed for mounting on a common 35 mm top hat rail in a housing or a switching cabinet. For triggering a contactor or for direct switching of loads, a 1-pole potential-free relay (change-over contact) is available. The actual value is shown on a 3-digit LCD display.
Technical Data
| controller type | two-position-regulator |
| control system | P |
| power control | relay (change-over contact), 150000 switchings (AC 250 V / 10 A) |
| temperature sensor | Pt 100, PT 1000 (acc. to DIN EN 60751) |
| temperatue range | -200 ... +600 °C |
| degree of accuracy | 0.1 % |
| protection category | IP 20 (EN 60529) |
| mounting | on mounting rails 35 mm x 7.5 mm (EN 50022) |
| connection type | terminals for wire cross sections up to max. 2.5 mm² |
| case dimensions | 90 x 22.5 x 62 mm |
| case material | polycarbonate |
